Ampe kìm AC Hioki 3291-50 (1000A, True RMS)
Hãng sản xuất: HIOKI- Nhật
Model : 3291-50
Thông số kỹ thuật:
rue RMS) : 60.00/600.0/1000A
Cấp chính xác: ±1.5% rdg. ±5dgt
Chức năng lọc 180Hz at filter ON (-3dB)
Chức năng khác: Flip-open mechanism (but still retaining proper orientation of display), Back light, Maximum value display, Data hold, Auto power off
Hiển thị : Digital LCD, max. 6000dgt., 91 segments
Nguồn (CR2032) × 1, Continuous use 20 hours
Kích thước kìm: φ 30mm (1.18 in)
Kích thước và trọng lượng : 50mm W × 136mmH × 26mm D,
Phụ kiện kèm theo: hộp cứng 9757 ×1, Strap ×1, Hướng dẫn sử dụng ×1,pin CR2032×1
Basic specifications
AC Current
|
60.00/600.0/1000A, 3 ranges, 45Hz to 400Hz, True RMS
Basic accuracy: ±1.5% rdg. ±5dgt. (50/60Hz, filter ON)
|
AC Voltage
|
n/a
|
Frequency
|
n/a
|
Crest factor
|
2.8 and under (1.68 and under at 1000 A range)
|
Filter function
|
Cut off frequency 180Hz at filter ON (-3dB)
|
Output function
|
n/a
|
Other function
|
Flip-open mechanism (but still retaining proper orientation of display), Back light, Maximum value display, Data hold, Auto power off
|
Display
|
Digital LCD, max. 6000dgt., 91 segments
Display refresh rate: 1.1 sec or higher
|
Power supply
|
Coin type lithium battery (CR2032) × 1, Continuous use 20 hours
|
Core jaw dia.
|
φ 30mm (1.18 in)
|
Dimensions, mass
|
50mm (1.97 in) W × 136mm (5.35 in) H × 26mm (1.02 in) D, 115g (4.1 oz)
|
Supplied accessories
|
CARRYING CASE 9757 ×1, Strap ×1, Instruction manual ×1, Coin type
lithium battery (CR2032, for trial purposes only) ×1
|
