Bộ điều khiển nhiệt độ Dotech DQ1000

0₫

Nhà Sản Xuất Dotech
Mã Sản Phẩm DQ1000

Bộ điều khiển nhiệt độ Dotech DQ1000

Model: DQ1000

Hãng sản xuất: Dotech

Thông số kỹ thuật:

	Item		Specifications
General specifications	Control methode		MICRO-PROCESSOR
	Program size	Kbyte	64
	Display methode		LCD or VFD
	Clock & calendar		RTC CONTROLLER CHIP (OPTION)
	Compressor steps		2 STEPS or 3, 4 STEPS
	Re-heater steps		5 STEPS
	Humidifier steps		3 STEPS or 2 STEPS
	Temperature set	℃	5 ~ 50
	Humidity set range	%RH	10 ~ 80
	Temp diff. Range	℃	0.1 ~ 9.9
	Humidity diff. Range	%RH	0.1 ~ 9.9
	Digital input		Isolated, 16 POINT
	Digital output		Relay Contact, 16 POINT
	Temp - sensor		Thermistor 1.0 Kohm, 1 POINT
	Rh - sensor		Capacitive Humidity Sensor, 1 POINT
	Comm. Port		232C 1CH, 232C or 485 1CH (OPTION)
	Oper. Temperature	℃	-10 ~ 70
	Operating humidity	%RH	20 ~ 80 (NON-CONDENSTAION)
	Storage temp.	℃	-20 ~ 80
	Insulation resist	㏁	100 (500VDC)
	Dielectric strengh		500VAC, 60SEC(LEAKAGE CURRENT 1mA MAXIMUM)
	In-out connector		5.0mm PITCH, SCREW & PLUG TYPE
	Net weight	g
	External dimension	mm
Power	Supply votage	VDC	24VDC (±2VDC)
	Ripple content	MAX	10%, Vp-p
	Power consumption	MAX	APR. 15W(AT FULL POWER). Recommend. VSF15-24

Bộ điều khiển nhiệt độ Dotech DQ1000

Model: DQ1000

Hãng sản xuất: Dotech

Thông số kỹ thuật:

	Item		Specifications
General specifications	Control methode		MICRO-PROCESSOR
	Program size	Kbyte	64
	Display methode		LCD or VFD
	Clock & calendar		RTC CONTROLLER CHIP (OPTION)
	Compressor steps		2 STEPS or 3, 4 STEPS
	Re-heater steps		5 STEPS
	Humidifier steps		3 STEPS or 2 STEPS
	Temperature set	℃	5 ~ 50
	Humidity set range	%RH	10 ~ 80
	Temp diff. Range	℃	0.1 ~ 9.9
	Humidity diff. Range	%RH	0.1 ~ 9.9
	Digital input		Isolated, 16 POINT
	Digital output		Relay Contact, 16 POINT
	Temp - sensor		Thermistor 1.0 Kohm, 1 POINT
	Rh - sensor		Capacitive Humidity Sensor, 1 POINT
	Comm. Port		232C 1CH, 232C or 485 1CH (OPTION)
	Oper. Temperature	℃	-10 ~ 70
	Operating humidity	%RH	20 ~ 80 (NON-CONDENSTAION)
	Storage temp.	℃	-20 ~ 80
	Insulation resist	㏁	100 (500VDC)
	Dielectric strengh		500VAC, 60SEC(LEAKAGE CURRENT 1mA MAXIMUM)
	In-out connector		5.0mm PITCH, SCREW & PLUG TYPE
	Net weight	g
	External dimension	mm
Power	Supply votage	VDC	24VDC (±2VDC)
	Ripple content	MAX	10%, Vp-p
	Power consumption	MAX	APR. 15W(AT FULL POWER). Recommend. VSF15-24
