Máy đo 3 chiều Hexagon CROMA

0₫

Nhà Sản Xuất Hexagon
Mã Sản Phẩm CROMA

Mô tả
Bình luận

Máy đo 3 chiều Hexagon CROMA

Model: CROMA

Hãng sản xuất: Hexagon

Thông số kỹ thuật:

All aluminium structure
Robust frame with hard anodised aerometal beam and Z-axis offers temperature consistency as well as a reduced mass of moving parts and force of inertia to ensure high accuracy during high-speed movement.

Patented triangular beam
The triangular beam design offers a lower centre of gravity, better stiffness and more reliable motion compared to rectangular and cross beams.

Integral dovetail guide way
Integral dovetail guide way on Y-axis reduces the machine weight and helps prevent motional swings during the inspection process to ensure measuring accuracy and stability.

Self-cleaning air bearings
All three axes run on high-precision self-cleaning air bearings, providing smooth movement that reduces wear on the guide ways to maximise equipment durability and minimise repair costs.

High-precision optical scales
European-import, high-precision optical scales installed with one end fixed and the other freely extensible ensures linear expansion and contraction with temperature changes to mitigate the impact of thermal deformation.
DC servo motors
All three axes are driven by DC servo motors, providing stable movement and exact positioning to support accurate probe location and overall measurement.

Specially-designed control system
The IDC-I control system, designed by Hexagon Metrology specifically for the CROMA range, improves the dynamic performance and measuring capabilities of the machine.

Machine Type			CROMA564		CROMA686	CROMA8106	CROMA8126
Strokes (mm)	X		500		600	800	800
	Y		600		800	1000	1200
	Z		400		600	600	600
Measuring range (mm)	Dx		634		734	934	934
	Dz		144		144	144	144
	Dz1		594		794	794	794
Working plate (mm)	Ph		783		783	805	805
	Py		1155		1355	1555	1755
Support (mm)	Sy		824		978	1178	1378
	Sy1		356		379	379	379
Overall size (mm)	Lx		1050		1150	1350	1350
	Ly		1535		1735	1935	2135
	Lz		2247		2647	2729	2729
Max. part weight			300		300	500	500
Machine weight (kg)			590		730	1074	1196
MPEe (μm)			2.8 + L / 300		2.8 + L / 300	3.0 + L / 300	3.0 + L / 300
Probe / Sensor	Manual or automatic
Scales resolution (μm)		0.078		0.078		0.078	0.078
Max. 3D speed (mm/s)		520		520		520	520
Max. 3D acceleration (mm/s2)		1730		1730		1730	1730
Air pressure		120 Nl / min, 0.45 Mpa		120 Nl / min, 0.45 Mpa		120 Nl / min, 0.45 Mpa	120 Nl / min, 0.45 Mpa
Operating temperature		20±2°C		20±2°C		20±2°C	20±2°C
Temperature gradients:
Air temperature variation		1°C / h - 2°C / 24h		1°C / h - 2°C / 24h		1°C / h - 2°C / 24h	1°C / h - 2°C / 24h
Air temperature gradient		1°C / m		1°C / m		1°C / m	1°C / m
HumidityOMA		45% - 75%		45% - 75%		45% - 75%	45% - 75%
