Model
|
DHV-1000
|
DHV-1000/Z
|
MHV-1000
MHV-2000
|
XHV-1000
|
MHV-1000/Z
MHV-2000/Z
|
Tes Force
|
N
|
0.098, 0.246, 0.49, 0.98, 1.96, 2.94, 4.90, 9.80 ( MHV-2000/Z 19.61)
|
Gf
|
10, 25, 50, 100, 200, 300, 500, 1000 ( MHV-2000/Z 2000)
|
Lens/ indenterswitch
|
With Hand Turret
|
Whit Motorized
Turret
|
With Hand Turret
|
Whit Motorized Turret
|
Dwell time of the
test force
|
(5-60)S
|
Amplification of
the Microscope
|
200x , 400x
|
100x, 400x
|
200x , 400x
|
Carriage Control
|
Automatic (loading/holding-up of the load/unloading)
|
Min. Graduation
Value of the Testing
Drum Wheel
|
0.01μm
|
Test Field
|
1HV-2967HV
|
X-Y Testing Table
|
Size: 100x100 mm, Stroke: 25 x 25 mm, Resolution Rate: 0.01 mm
|
Language
|
English
|
Specimen
|
The Max Height: 100mm
|
Energy-saving mode
|
After 10 minutes of non-use it enters the repose mode automatically.
|
Light Source/
Power Supply
|
110v/220v, 50-60Hz / Halogen lamp
|
Output
|
No built-in printer
|
with built-in printer and a RS 232 serial interface
|
Loading Motor
|
3W, 100V AC, 4 rpm
|
Power source
|
AC 220V, 50/60Hz
|
Total Power
Consumption
|
≤ 60W
|
Main Accessories
|
Vickers indenter, Objective 10x, 40x , Digital Micro lens 10x, X-Y Table,
Thin specimen Test table, Fork-shaped Test table, Fine Wire Tes Table,
adjustable Screws, Level Gauge, RS-232 Cable, micro Vickers Hardness Test Block, etc
|
Weight /
Package Dimension
|
Gross Weight: 44kg, Net Weight: 30kg/ 595x365x780(mm)
|
