Máy đo phổ màu sắc SPIC-300

Model

AW Model

BW Model

Wavelength range

380 nm ~ 760 nm

380 nm ~ 780 nm

SBCT

No

Yes

Receptor window

Ф8 mm

(Ф8 mm + Ф3.5 mm)

Wavelength accuracy

± 0.5 nm

Illuminance accuracy

± (4% reading+1 digit）

±（3% reading+1 digit）

Stray light

≤ 0.3%

Integration time

range

0.1 ms ~ 5000 ms

Illuminance range

1 lx ~ 100k lx

0.01 lx ~ 200k lx

CCT

1,000K～100,000K

Accuracy of chromaticity coordinate

±0.001（Relative to the standard light source whose stability is better than ±0.0001 and NIM traceable calibrated value）

CRI

Ra; Ri (i=1~14) (Specially R15)

Power supply

Rechargeable Lithium battery (3.7V), continuously works for 4h

Communication

interface

USB, Bluetooth, WIFI

Data Storing

6 G

Weight

 320 g (with battery)
