Máy đo phóng xạ, bức xạ RPD 9DP-1

Máy đo phóng xạ, bức xạ RPD 9DP-1

Model: 9DP-1

Hãng sản xuất: RPD

Thông số kỹ thuật:

The Model 9DP-1 ion chamber meter is specially designed for radiography work where pulsed fields are being measured. This instrument correctly integrates 50 nanosecond pulses (and wider) that other systems typically miss or measure inaccurately. This instrument measures both exposure and exposure rate and can simultaneously display the exposure rate, integrated value and highest rate seen by the instrument. The integrated value can be reset (if desired) using one of the four convenient front-panel mounted buttons. The buttons also control instrument power, function selection, setting the speaker volume and acknowledging alarms.
Special Design for Measuring Pulsed Fields

Low Pressure Chamber is Non Hazmat

0–500 mSv/h (0–50 R/hr) Range

Sunlight Readable Color Display

Auto Zeroing & Ranging

Rechargeable Batteries

Alarming Capability

Rate, Integrate & Peak Hold Readouts

Data Logging

USB Connectivity

Free Firmware Updates through Internet
The detector chamber is only pressurized to 1.36 atmospheres (20 psi), thus avoiding all (USA) HAZMAT concerns for shipping and handling. The stunning 256-color, bit-mapped display provides an optimized presentation of the data and is accompanied with icons informing the user of the active functions and instrument status. Alarms are manifested using color changes on the display and an acknowledgeable audio output.

The instrument is powered using NiMH type rechargeable batteries that deliver up to 30 hours operation between charges. Measurements can be logged to an industry standard, USB thumb drive plugged into the instrument USB port. Data are written in csv format for convenient retrieval by a PC spreadsheet or database program.

The Model 9DP-1 is part of the new Dimension series of meters employing state-of-the-art technologies that deliver tremendous capability, user friendliness, and convenient PC connectivity. The built-in USB port facilitates password-protected access to parameter settings via direct connection to a USB keyboard thus foregoing any need to install PC application software or dealing with operating system compatibility issues. An optional Dimension PC Windows™ interface program that enables total control over the instrument and performs calibration is also available.
Specifications
Radiation Detected: Gamma & X-rays above 25 keV; beta above 1 MeV, correctly integrates pulsed fields with 50 nanosecond pulse widths

Operating Ranges:
With R/h units: 0–5 mR/h, 0–50 mR/h, 0–500 mR /h, 0–5 R/h, 0–50 R/h
With Sv/h units: 0–500 µSv/h, 0–5 mSv/h, 0–50 mSv/h, 0–500 mSv/h

Chamber Volume: 220 cc volume pressurized to 1.36 atmospheres (20 psi)

Accuracy: +/-10%
Response Time: 5 seconds in lowest range, 2 seconds in all other ranges, when measuring from 10% to 90% of final value
Measurement Readouts: Simultaneous display of rate and either the integrated reading or highest rate (peak hold)
Included Functions: Integrated reading, peak reading, range lock (0-50 R/h) for reading pulsed fields
Data Logging: Data is stored to detachable USB thumb drive in CSV format for easy retrieval by PC spreadsheet/database programs. Data points include real-time clock generated date and time with rate, integrated reading, and instrument status. Logging time intervals are set by PC interface program or standard USB keyboard.
LCD Display: 3.5” (8.9 cm) diagonal, 240 H x 320 W pixels, TFT active matrix, 262,144 colors, 220 cd/m²
User Controls: 4 pushbuttons: Instrument on/off, peak rate/integrate mode, audio on/off, alarm acknowledge/meter reset/clearing integrated dose or peak rate
Automatic Functions: Auto ranging, auto zeroing, auto LCD backlighting
Audio Outputs: Built-in unimorph speaker, > 60 dB at 2’ (0.6 meters) An optional audio jack can be installed for connecting to an external headset (not supplied).
Alarms: Two levels of radiation alarms available, each is user programmable throughout entire readout range. Other alarms include low battery and various detector failures.
Temperature Range: -20 to 50 °C (-4 to 122 °F)
Power: Eight rechargeable AA NiMH batteries, supplied with wall charger for direct connection to instrument
Battery Life: 12 to 30 hours between charges, depending upon use of backlighting
USB Interface: Single USB port, may be connected directly to a USB keyboard to facilitate password-protected parameter changes, accepts USB thumb drive for storing logged data, optional interface kit facilitates connection to a PC for parameter editing and calibration
Construction: Durable molded plastic with internal metal support
Size: 4.6” W x 9.6” L x 8.6” H (11.6 x 24.5 x 21.9 cm)
Weight: 3.3 lb (1.5 kg), including batteries
