Máy thử moment xoắn lò xo Digitech ASP-100/ASP-100S

0₫

Nhà Sản Xuất Digitech
Mã Sản Phẩm ASP-100/ASP-100S

Máy thử moment xoắn lò xo Digitech ASP-100/ASP-100S

Model: ASP-100/ASP-100S

Hãng sản xuất: Digitech

Specification / Model	ASP-100/ASP-100S	ASP-200/ASP-200S	ASP-500/ASP-500S
Capacity	1kN（100kgf）	2kN（200kgf）	5kN（500kgf）
Load resolution	10mN（1gf）	100mN（10gf）	100mN（10gf）
Length resorution	0.01mm	0.01mm	0.01mm
Test speed	1～600mm/min	1～600mm/min	1～600mm/min
Max test length	600mm	600mm	600mm
Anvil diameter	150Φ	150Φ	150Φ
Testing machine standard	JIS B 7738"Verification of the coil spring compression and tensile testing machine" class 0.5 compatible
Transportation	Precise ball screw / servo motor
Safety measures	Mechanical limit stop / Over load stop / emergency stop SW
Communication method	USB1.1	USB1.1	USB1.1
Dimension	W770×H1277×D390	W770×H1277×D390	W770×H1277×D390
Weight	approx.190kg	approx.190kg	approx.190kg
Power source	AC100 or 220V	AC100 or 220V	AC100 or 220V

Specification / Model	ASP-1000/ASP-1000S	ASP-2000/ASP-2000S
Capacity	10kN（1000kgf）	20kN（2000kgf）
Load resolution	100mN（10gf）	1N（100gf）
Length resorution	0.01mm	0.01mm
Test speed	1～600mm/min	1～600mm/min
Max test length	800mm	800mm
Anvil diameter	200Φ	200Φ
Testing machine standard	JIS B 7738"Verification of the coil spring compression and tensile testing machine" class 0.5 compatible
Transportation	Precise ball screw / servo motor
Safety measures	Mechanical limit stop / Over load stop / emergency stop SW
Communication method	USB1.1	USB1.1
Dimension	W870×H1770×D390	W870×H1770×D390
Weight	approx.220kg	approx.260kg
Power source	AC100 or 220V	AC100 or 220V

Máy thử moment xoắn lò xo Digitech ASP-100/ASP-100S

Model: ASP-100/ASP-100S

Hãng sản xuất: Digitech

Specification / Model	ASP-100/ASP-100S	ASP-200/ASP-200S	ASP-500/ASP-500S
Capacity	1kN（100kgf）	2kN（200kgf）	5kN（500kgf）
Load resolution	10mN（1gf）	100mN（10gf）	100mN（10gf）
Length resorution	0.01mm	0.01mm	0.01mm
Test speed	1～600mm/min	1～600mm/min	1～600mm/min
Max test length	600mm	600mm	600mm
Anvil diameter	150Φ	150Φ	150Φ
Testing machine standard	JIS B 7738"Verification of the coil spring compression and tensile testing machine" class 0.5 compatible
Transportation	Precise ball screw / servo motor
Safety measures	Mechanical limit stop / Over load stop / emergency stop SW
Communication method	USB1.1	USB1.1	USB1.1
Dimension	W770×H1277×D390	W770×H1277×D390	W770×H1277×D390
Weight	approx.190kg	approx.190kg	approx.190kg
Power source	AC100 or 220V	AC100 or 220V	AC100 or 220V

Specification / Model	ASP-1000/ASP-1000S	ASP-2000/ASP-2000S
Capacity	10kN（1000kgf）	20kN（2000kgf）
Load resolution	100mN（10gf）	1N（100gf）
Length resorution	0.01mm	0.01mm
Test speed	1～600mm/min	1～600mm/min
Max test length	800mm	800mm
Anvil diameter	200Φ	200Φ
Testing machine standard	JIS B 7738"Verification of the coil spring compression and tensile testing machine" class 0.5 compatible
Transportation	Precise ball screw / servo motor
Safety measures	Mechanical limit stop / Over load stop / emergency stop SW
Communication method	USB1.1	USB1.1
Dimension	W870×H1770×D390	W870×H1770×D390
Weight	approx.220kg	approx.260kg
Power source	AC100 or 220V	AC100 or 220V
