Thiết bị đo cường độ UV Custom UVC-254
Model: UVC-254
Hãng sản xuất: Custom
Thông số kỹ thuật:
Electric performance
Measurement range
199.9μW / ㎠, 1.999mw / ㎠, 19.99mw / ㎠
resolution
0.1μW / ㎠, 0.001mw / ㎠, 0.01mw / ㎠
Measurement accuracy
± (2% FS + 2dgt)
Wavelength sensitivity characteristics
248 ~ 260nm
General specification
sensor
UV sensor
display
3.5-digit LCD display
sampling
2.5 times / sec.
Over display
"-----"Show
Use temperature and humidity
0 ~ + 50 ℃, 80% RH or less (without condensation)
Storage temperature and humidity
-10 ~ + 50 ℃, 70% RH or less (without condensation)
Power supply
One 9V type battery ×
Battery life
About 100 hours (when using alkaline batteries)
Dimensions and weight
[Body] W72 × H180 × D32mm
[Sensor] φ38 × H27mm, code length of about 400mm
[Weight] about 335g
Accessories
UV sensor, carrying case, instruction manual
Option
WINDOWS XP-compatible software + communication cable: SWS-001U→ complete production
Proofreading
Yes
